ATV650D55N4Complementario
Tipo de montaje Montaje en pared
Tensión de salida <= de la potencia de la tensión de alimentación Corriente temporal permisible 1.5 x In during 60 s (heavy duty) 1.1 x In during 60 s (normal duty) Compensación desliz. motor Regulable No disponible en motores de imanes permanentes Automático sea cual sea la carga Regulable Rampas de aceleración y deceleración Líneal ajustable por separado de 0,01...9999 s Frenado hasta parada Mediante inyección de CC Tipo de protección Safe torque off: motor Motor phase break: motor Thermal protection: drive Safe torque off: drive Overheating: drive Overcurrent between output phases and earth: drive Overload of output voltage: drive Short-circuit protection: drive Motor phase break: drive Overvoltages on the DC bus: drive Line supply overvoltage: drive Line supply undervoltage: drive Line supply phase loss: drive Overspeed: drive Break on the control circuit: drive Thermal protection: motor Resolución de frecuencia Analog input: 0.012/50 Hz Display unit: 0.1 Hz Consecutivo, seguido, continuo, adosado Line side: screw terminal 35...50 mm²/AWG 3...AWG 1 Motor: screw terminal 35...50 mm²/AWG 2...AWG 1 Control: removable screw terminals 0.5...1.5 mm²/AWG 20...AWG 16 Tipo de conector RJ45 (on the remote graphic terminal) for Modbus serial RJ45 (on the remote graphic terminal) for Ethernet/Modbus TCP Bloqueo estándar Half duplex, full duplex, autonegotiation Ethernet/Modbus TCP Número de direcciones 1…247 for Modbus serial Método de acceso Slave Modbus TCP Suministro Internal supply for reference potentiometer (1 to 10 kOhm): 10.5 V DC +/- 5 %, <10 mA, protection type: overload and short-circuit protection Internal supply for digital inputs and STO: 24 V DC (21…27 V), <200 mA, protection type: overload and short-circuit protection External supply for digital inputs: 24 V DC (19…30 V), <1.25 mA, protection type: overload and short-circuit protection Señalizaciones en local 3 LEDs (dual colour) for embedded communication status 4 LEDs (dual colour) for communication module status 1 LED (red) for presence of voltage 3 LEDs for local diagnostic Anchura 345 mm Altura 1250 mm Profundidad 375 mm 4 Peso del producto 87 kg Número de entrada analógica 3 Tipo de entrada análogica AI1, AI2, AI3 software-configurable current: 0...20 mA/4...20 mA, impedance: 250 Ohm, resolution 12 bits AI1, AI2, AI3 software-configurable voltage: 0...10 V DC, impedance: 30 kOhm, resolution 12 bits Número de entrada digital 8 Entrada discreta DI5, DI6 programmable as pulse input: 0…30 kHz, 24 V DC (<= 30 V) STOA, STOB safe torque off, 24 V DC (<= 30 V), impedance: > 2.2 kOhm
DI1…DI6 programmable, 24 V DC (<= 30 V), impedance: 3.5 kOhm Fase marcador DI5, DI6: discrete input level 1 PLC conforming to IEC 65A-68 STOA, STOB: discrete input level 1 PLC conforming to EN/IEC 61131-2 DI1...DI6: discrete input level 1 PLC conforming to EN/IEC 61131-2 Entrada lógica Negative logic (sink) (DI1...DI6), > 16 V (state 0), < 10 V (state 1) Positive logic (source) (DI5, DI6), < 0.6 V (state 0), > 2.5 V (state 1)
Positive logic (source) (STOA, STOB), < 5 V (state 0), > 11 V (state 1)
Positive logic (source) (DI1…DI6), < 5 V (state 0), > 11 V (state 1)
Número de salida analógica 2
Tipo de salida análogica Software-configurable current AO1, AO2: 0…20 mA, resolution 10 bits
Software-configurable voltage AO1, AO2: 0…10 V DC impedance 470 Ohm, resolution 10 bits
Duración de muestreo 5 Ms +/- 1 ms (DI5, DI6) – discrete input
5 Ms +/- 0.1 ms (AI1, AI2, AI3) – analog input
10 Ms +/- 1 ms (AO1) – analog output
2 ms +/- 0.5 ms (DI1…DI4) – discrete input
Precisión +/- 1 % AO1, AO2 for a temperature variation 60 °C analog output
+/- 0.6 % AI1, AI2, AI3 for a temperature variation 60 °C analog input
Error lineal AO1, AO2: +/- 0.2 % for analog output
AI1, AI2, AI3: +/- 0.15 % of maximum value for analog input
Numero de salidas relé 3
Tipo de salida de relé Configurable relay logic R2: sequence relay NO electrical durability 100000 cycles
Configurable relay logic R3: sequence relay NO electrical durability 100000 cycles
Configurable relay logic R1: fault relay NO/NC electrical durability 100000 cycles
Tiempo de actualización Relay output (R1, R2, R3): 5 ms (+/- 0.5 ms)
Corriente mínima de conmutación Relay output R1, R2, R3: 5 mA at 24 V DC
Intensidad de conmutación máxima Relay output R1, R2, R3 on resistive load, cos phi = 1: 3 A at 30 V DC
Relay output R1, R2, R3 on inductive load, cos phi = 0.4 and L/R = 7 ms: 2 A at
250 V AC
Relay output R1, R2, R3 on inductive load, cos phi = 0.4 and L/R = 7 ms: 2 A at
30 V DC
Relay output R1, R2, R3 on resistive load, cos phi = 1: 3 A at 250 V AC
Aislamiento Aislamiento galvánico entre terminales de alimentación y control
Variable speed drive application selection Edificios – HVAC Compresor centrifugo
Motor power range AC-3 55…100 kW at 380…440 V 3 phases
